SPECIFICATIONS

Engine Type CB250-F, Single Cylinder, 4-Stroke, Air Cooling, SOHC

Displacement 249.9 ml

Max Power 14kw / 8500rpm – 19 Hp

Max Torque 18/6500 N.m/r/min

Compression Ratio 9.25:1

Shift Type Manual Wet Multi-Plate, Constant mesh, two stage transmission, 5-Gears

Start Type Electric & Kick Start

Carburetor PE30A-8L

Ignition Digital CDI

Drive Train #520 Chain, FT: 13T/RR: 47T Sprocket

PERFORMANCE

Front Fork Φ51*Φ54-830mm Inverted Hydraulic Dual Adjustable Forks

Rear Shock φ 10 * 450/A40N0A/without air cup, built-in airbag, adjustable white spring/upper φ 10 * 22/lower φ 10*20

Front Wheel 7116 Aluminum Rim, Gravity Cast Hub, FT: 1.6 x 21

Rear Wheel 7116 Aluminum Rim, Gravity Cast Hub, RR: 2.15 x 18

Front Tires 80/100-21

Rear Tires 100/90-18

Front Brake Dual Piston Caliper, 240mm Disc

Rear Brake Single Piston Caliper, 240mm Disc

DETAILS

Frame Central Tube High Strength Steel Frame

Swing-Arm Steel flat fork Swingarm, L=540mm

Handle Bar Conical steel pipe

Overall Size 2000x820x1230 mm

Packing Size 1710x465x860mm

Wheel Base 1330 mm

Seat Height 900 mm

Ground Clearance 320 mm

Fuel Capacity 6.5 L / 1.72 Gal.

N.W 108KG

G.W 133KG
